JuLiBao E58S narrow width high speed label weaving machinde

【Product Overview】

"E58S" narrow width high speed label weaving loom, that is our company combines with italian famous loom manufacture enterprise, use many latest technology achievements of the global, such as automati

1. Advantages of speed, to realize 560-600 rpm normal working speed.

2. Beating-up fast, to realize the demand of high quality lebel easily, reach colorful cubic effect and compact weaving.

3. The whole machine reach electric automatic control, condermn all the clutch, don't need to adjust and replace the cluth, also eliminate the fault hidden dangers, make the loom operate well and fast.

4. The loom speed can be automatic controlled, according to different weft, adjust the speed automatically.

5. Fuse the loom and lebel control system circuit, make the operater control the whole machine easily.

6. Depend on Italian technology, the electric control system has complete functions, simple, efficient, high standards control and low failure funning.

7. Using "pulse width modulation" Thermal cutting system, there are low power, low heat, low fault characteristics and high precision current control, the precison can reach to hundredth.

8. The thermal cutting system can automatically adapt the condition of machine station, no matter speed change or manual coiling, the thermal cutter will adjust the temperature automatically.

9. Using direct drive motor control the whole machine, both high speed and low speed can be controlled by the main motor.

10. The whole machine will turn to dormant state when the machine station stop running, and that will save power.

11. Mechanied weft cutter insures cutting weft in an optimal instant, independent on types and materials of the weft.

[ Main technical parameters ]

Loom: Panter narrow width high speed loom Speed: 560-600rpm Reed width: 1450mm/1600mm Weft detecting: Doubler weft detection, import 8-12 holes weft detector Weft tension: Double-twist electronic weft storage device adjustment Weft colors: 8-12 colors selector from jacquard Weft cutter: Electronic weft catten Weft searching system: Electronic automatic shed detecting Weft searching system: Electronic stepless adjustment Main motor: Direct drive motor

Repeats: 6/7 repeats for taffeta(1 repeat-200mm)          (self-select according to customer)          12/14 repeats for stain(1 repeat-100mm)          (self-select according to customer) Jacquard：STAUBLI DX high speed self-test jaquard System: JC6 Electronic control system Thermal cutting: TCS I thermal cutting system(TCS II as althernative choice) automatically keep constant temperature Stereotype: Full width temple, specially-made heating plate, excellent setting effect Power: 8KW(approx) Size: 4300mm(L)×1800mm(W)×3800mm(H) Notice: Workshop height required ≥4000mm
